INDUSTRIAL BULK STORAGE
INDUSTRIAL
ROUND SILOS
Smooth-Wall storage Built for Reliable Material Flow
Fully welded round silos engineered for reliable dry bulk material storage and consistent product flow. Available in carbon or stainless steel, each silo is custom-designed around your material, capacity, discharge requirements, and facility layout.
PERFORMANCE SPECIFICATIONS
MASS FLOW
DESIGNED FOR RELIABLE DISCHARGE
FULLY WELDED
HEAVY-DUTY CONSTRUCTION
3 TO 12 FT
DIAMETER OPTIONS
CUSTOM
OUTLET CONFIGURATIONS
ROUND SILOS FOR RELIABLE DRY BULK MATERIAL STORAGE
Scott Equipment round silos provide durable, high-capacity storage for powders, grains, feed ingredients, minerals, pellets, plastics, and other dry bulk materials. Fully welded construction and smooth interior walls help reduce material buildup, bridging, and hang-ups while promoting reliable product flow.
Each round silo is custom-engineered around your material characteristics, required storage capacity, facility layout, support structure, and discharge requirements. Silos are available in carbon or stainless steel with multiple finish, outlet, and support configurations.
Scott currently lists diameters from 3 to 14 feet, capacities up to 10,000 cubic feet, and heights over 75 feet.
Smooth-Wall Design
Smooth interior walls help reduce ledges, buildup, bridging, and material hang-ups for cleaner, more reliable product flow.
Custom Engineered
Each silo is sized and configured around your material, storage capacity, facility layout, support structure, and discharge requirements.
Built for Strength
Fully welded carbon- or stainless-steel construction provides long-term durability for demanding bulk storage applications.
KEY FEATURES
Smooth interior & exterior walls
Custom outlet configurations
Built for mass flow
Carbon steel or stainless steel
Mill finish to 120-grit finish
Skirt, leg, lug, or load cell support options
SPECIFICATIONS
| SPECIFICATION | DETAILS |
| Diameter | 3 ft. to 14 ft. |
| Capacity | up to 10,000 ft. ³ |
| Height | Over 75 ft. available |
| Materials | Carbon or Stainless steel |
| Finish | Mill finish to 120-grit, RA60 max |
| Support Options | Skirt, leg, lug, load cell structure |
| Shipping | One unit or split sections |
Common Applications
FOOD INGREDIENTS
Dry powders • Sugars & starches • Baking ingredients
FEED, AGRICULTURE & GRAINS
Rice • Feed ingredients • Premixes • Minerals • Whole grains
PET FOOD
Dry ingredients • Protein meals • Vitamins • Premixes
CHEMICALS & MINERALS
Dry chemical powders • granules • Bulk raw materials
AQUA FEED
Feed ingredients • Meals • Proteins • Premixes • Minerals
FLOUR
Wheat flour • Specialty flours • Dry milling products
RECYCLING
Recovered materials • Processed dry products • Recycled bulk materials
Built for Easy Transport. Designed for Efficient Installation.
Scott Equipment round silos can be shipped as a complete unit or in split sections depending on silo dimensions, transportation requirements, and installation conditions. Split-section construction allows larger silos to be transported efficiently and assembled at the installation site.
ROUND SILO FAQs
What is an industrial round silo?
An industrial round silo is a cylindrical storage vessel for powders, grains, pellets, ingredients, minerals, and other dry bulk materials before processing or discharge.
What materials can be stored in a round silo?
Round silos can be engineered for a wide variety of dry bulk materials, including grains, feed ingredients, food powders, flour, minerals, chemicals, plastic pellets, recycled materials, and other free-flowing or flow-sensitive products.
What sizes are Scott Equipment round silos available in?
Scott Equipment currently offers round silos ranging from 3 to 14 feet in diameter, with capacities up to 10,000 cubic feet and heights over 75 feet.
What is mass flow in a silo?
Mass flow occurs when material moves toward the outlet throughout the vessel during discharge rather than leaving large stagnant regions along the silo walls. Proper hopper and outlet design is important for achieving reliable material flow.
How are round silos supported?
Scott Equipment offers skirt, leg, lug, and load-cell support configurations to meet application and installation requirements.
How are large round silos shipped?
Depending on the silo size and transportation requirements, Scott round silos can be shipped as a single unit or in split sections for field assembly.
what are you waiting for?
CONTACT US TODAY TO LEARN ABOUT ROUND BULK STORAGE SILO OPTIONS
